Drawn steel

Round, square, hexagonal and flat
– this is how versatile the drawn steel is!

Drawn steel is available in various surface treatments such as: drawn, flaked, ground or polished.

All of this is now at your fingertips thanks to KönigStahl!

icon

flat drawn


icon Certificates and approvals
icon Material and delivery terms
icon Dimensions scope
with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204
Tolerance h11/h12:
EN 10277/EN 10278 S235JRC/S235JRC+C (1.0038/1.0122 )
from 8x2mm to - 500x80mm - L 3-3,5m / 6 - 6,5 m
with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204
Tolerance h11/h12:
EN 10277, EN 10278 S355J0 / S355J2 / S355J2C+C
(1.0553 / 1.0577 / 1.0569 )
from 16x10mm to 180x60 mm
L ca. 3 - 3,5 m / 6 - 6,5 m
with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204
Tolerance h11/h12:
EN 10277, EN 10278 - C45 / C45E / C45R+C (1.1191 / 1.1201 )
from 10x5mm to 250x60 mm
L ca. 3 - 3,5 m / 6 - 6,5 m

icon

drawn square rods


icon Certificates and approvals
icon Material and terms of delivery
icon Dimensions scope
with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204
Tolerance h11/h12:
EN 10277/EN 10278 - S235JR / S235JRC +C (1.0038 / 1.0122) / S355J2C
+C(1.0579) / C45+C
(1.0503)
S235JRC+C (1.0122):
from 10 mm to 150 mm - L 3-3,5 m

S355J2C +C (1.0579):
from 20 mm to 80 mm - L 6-6,5 m

C45+C (1.0503):
from 10 mm to 80 mm - L 6-6,5 m

icon

hexagonal bars


icon Certificate and approvals
icon Material and delivery terms
icon Dimensions scope
with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204
Tolerance h11:
EN 10277/EN 10278 - C45+C (1.0503) /
11SMnPb37+C (1.0737)
C45+C (1.0503):
from 13mm to 80 mm - L 3-3,5 m


11SMnPb37+C (1.0737):
from 17 mm to 46 mm - L 3-3,5 m

icon

bright round steel


icon Certificates and approvals
icon Materials and delivery terms
icon Dimensions scope

GROUND ROADS


with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204

GROUND ROADS


Tolerance h6 (h7):
EN 10277/EN 10278 - C45:2010 1.0503

GROUND ROADS


C45+C+SL (1.0503):
from Ø 8 mm to Ø 80 mm - L 3-3,5 m

DRAWN / PEELED


with certificate 2.2 according to EN 10204 on request with certificate 3.1 according to EN 10204

Speciale features:

exceptional dimensional accuracy
good surface quality
large selection of material grades and dimensions

DRAWN / PEELED


Tolerance h9:
EN 10277/EN 10278

Structural steel:
S235JRC+C/SH (1.0122) / S355J2C +C/SH (1.0579) / C45+C/SH (1.0503)

Steel for carburising:
16MnCr(S)5+C/SH (1.7131/1.7139) / 20MnCr(S)5+C/SH (1.7141/1.7149)

Free cutting steel:
11SMn37/30+C/SH (1.0736/1.0715) / 11SMnPb37/30+C/SH (1.0737/1.0718)

heat treatable steel:
42CrMo4+QT+C/SH (1.7225)

DRAWN / PEELED


S235JRC+C/SH (1.0122):
from Ø 4 mm to Ø 130 mm - L 3-3,5 m / 6-6,5 m

S355J2C +C/SH (1.0579):
from Ø 6 mm to Ø 100 mm - L 3-3,5 m / 6-6,5 m

C45+C/SH (1.0503):
from Ø 5 mm to Ø 110 mm - L 3-3,5 m / 6-6,5 m

16MnCr(S)5+C/SH (1.7131/1.7139):
from Ø 12 mm to Ø 35 mm - L 3-3,5 m / 6-6,5 m

20MnCr(S)5+C/SH (1.7141/1.7149):
from Ø 12 mm to Ø 35 mm - L 3-3,5 m / 6-6,5 m

11SMn37/30+C/SH (1.0736/1.0715):
from Ø 10 mm to Ø 85 mm - L 3-3,5 m / 6-6,5 m

11SMnPb37/30+C/SH (1.0737/1.0718):
von Ø 5 mm bis Ø 110 mm - HL 3-3,5 m / 6-6,5 m

42CrMo4+QT+C/SH (1.7225):
from Ø 8 mm to Ø 80 mm - L 3-3,5 m / 6-6,5 m

icon

ROLLED BARS


icon Certification and approvals
icon Material and delivery termsicon Dimensions scope
with certificate 3.1 according to EN 10204Forged or rolled bars:
EN 10060, EN 10021
EN 10083-2, EN 10083-3, EN 10084
EN 1013, DIN 7527-6

C45 (1.0503) / C45E (1.1191) / C45R (1.2011)
16MnCr(S)5 (1.7131/1.7149), 20MnCr(S)5 (1.7147/1.7149)
42CrMo(S)4+QT (1.7225/1.7227)
C45 (1.0503) / C45E (1.1191) / C45R (1.2011):
from Ø 20 mm to 340 mm / 600 mm (forged) – L= 4-6m
16MnCr5 (1.7131), 20MnCr5 (1.7147),
16MnCrS5 (1.7139), 20MnCrS5 (1.7149)
:
from Ø 20 mm to 250 mm – L = 4-6 m
42CrMo4+QT (1.7225) / 42CrMoS4+QT (1.7227):
from Ø 20 mm to 330 mm – L = 4-6 m
